3201195726 WATER PLATE Epiroc RD22U Front Head Service Parts connect plate 3201 1957 26 Atlas

3201195726 water plate: fits Epiroc RD22U front heads. No leaks, no guesswork.

The 3201195726 water plate is a straightforward swap for the Epiroc RD22U front head – and it also slots right into older Atlas Copco rigs that run the 3201 1957 26 connect plate. If you are seeing water leaks around the front head, loosing flushing pressure, or pulling a head apart for a scheduled rebuild, this is the plate that restores proper water flow.

  • Direct bolt-on for RD22U and Atlas Copco ROC L8/L6 series
  • Corrosion-resistant alloy – stands up to mine water and washdowns
  • Port geometry matches OEM so you don’t fight with hose alignment
Get a Quote Back to For Epirco drifter
3201195726 WATER PLATE Epiroc RD22U Front Head Service Parts connect plate 3201 1957 26 Atlas
#275
Highlights
Key Advantages
  • Replaces Epiroc 3201195726 and Atlas Copco 3201 1957 26 – same bolt pattern, same port threads
  • Keeps water flow consistent to the shank and bit, which cuts down on overheat-related failures
  • Machined from a corrosion-resistant alloy that holds up in acidic or high-TDS mine water
  • Sealing lands are flat within 0.02 mm – tested at 1.5× operating pressure with zero weep
  • Every plate gets a dimensional check and a wet pressure test before it leaves the warehouse
Use Cases
Applications
  • Epiroc RD22U surface drill – front head water feed
  • Atlas Copco ROC L8, L6, and D-series rigs calling for 3201 1957 26
  • DTH water circulation – keeping hammer and bit cool on deep holes
  • Front head overhaul kits – drop-in when you are doing bearings, pistons, and seals
  • Open-pit and quarry blast-hole drilling with high-hour fleets
Specs
Technical Specifications
Part Number3201195726
Cross-Reference OEM3201 1957 26 (Atlas Copco)
Machine FitEpiroc RD22U front head; Atlas Copco ROC L8/L6/D-series
MaterialCorrosion-resistant alloy (similar to AISI 316 base with proprietary treatment)
FunctionWater routing plate between swivel and front head housing
MountingBolt-on – uses existing fastener pattern; gasket or O-ring seal face
Max Working Pressure25 bar (360 psi) continuous
Test Pressure37.5 bar (540 psi) – 1.5× safety factor
Weight0.82 kg (1.8 lbs)
Details
