Atlas Copco 3201195249 Guide 3201 1952 49 Drilling Rig Mining Machinery Parts Epiroc RD 22U

Keeps your RD‑series rock drill tracking straight — shift after shift

The Atlas Copco 3201195249 guide (also marked 3201 1952 49) slides into the feed beam of Epiroc RD 22U and RD 18U surface drills. Its job is simple: stop the rock drill from wandering under load. Made for the grit, water, and hammering common on mine benches and quarry faces, it helps you avoid premature wear on adjacent parts and unplanned downtime.

  • Direct swap for the worn guide in your RD feed system
  • Dimensionally identical to the factory‑fitted part
  • Ships in OEM packaging with date‑code traceability
Get a Quote Back to For Epirco drifter
Atlas Copco 3201195249 Guide 3201 1952 49 Drilling Rig Mining Machinery Parts Epiroc RD 22U
#287
Highlights
Key Advantages
  • Machined to factory specs — drops straight into RD 18U and RD 22U feed beams with no shimming or filing needed
  • Wear‑resistant alloy holds shape longer in abrasive drilling, cutting replacement frequency on high‑meterage sites
  • Full traceability: every guide is stamped with 3201195249 / 3201 1952 49 and supplied in OEM‑labeled packaging
  • Minimizes side‑to‑side play of the rock drill, reducing stress on feed cylinders and wear pads
Use Cases
Applications
  • Epiroc RD 22U — rock drill feed beam alignment
  • Epiroc RD 18U — rock drill feed beam alignment
  • Open‑pit production drilling fleets
  • Quarry and surface mining operations
  • Drilling contractor spare parts stock
  • Shop rebuilds and scheduled maintenance kits
Specs
Technical Specifications
Part number3201195249 (3201 1952 49)
Part descriptionGuide for rock drill feed beam
Fits modelsEpiroc RD 18U, RD 22U rock drills
FunctionLateral alignment and support of rock drill in feed
MaterialAlloy steel, wear‑resistant grade
Brand / OEMAtlas Copco / Epiroc
Approx. weight3.2 kg
Approx. dimensions (L × W × H)210 × 85 × 65 mm
Details
Detailed Description
Atlas Copco 3201195249 Guide 3201 1952 49 Drilling Rig Mining Machinery Parts Epiroc RD 22U

EPIROC - RD 18U

Ref No.Part No.Description
08311128801ROCK DRILL
00686925026PLUG
00686925027PLUG
53115223100DRILL COLLAR
103115028600DOME NUT
113115028700WASHER
173115145700SIDE BOLT
203115347383HYDRAULIC MOTOR
213115027700COUPLING
220335213000CIRCLIP
243115032700GASKET
253115354800NUT
303201195381ACCUMULATOR
353201195491RETURN ACCUM.
400088001621PRODUCT GRAPHICS
703176651200NIPPLE
713176651400NIPPLE
1003201195100FRONT PART COMP
1003201195252FRONT PART COMP
1013201195251FRONT PART
1053201195125GUIDE
1053201195249GUIDE
1103201195254FLUSHING HEAD
1103201195248FLUSHING HEAD
1113115336500CUP SEAL
1113115519000CUP SEAL
1203201195410CONNECTION
1210663212600O RING
1303115324500SEAL RING
1403201195127STOP RING
1403201195250STOP RING
1415730008000ORING
1420663614500ORING
1430663214300ORING
1513201195173COVER COMPL.
1523201195174COVER
1600666600060RADIAL LIP SEAL
1610335217600CIRCLIP
1700663615100ORING
1910102046000PIN
1950147140803SCREW. HEX HEAD
2013201195176GEAR HOUSING
2120544216200GREASE NIPPLE
2140686420103PLUG
2150653903800GASKET
2170666600030RADIAL LIP SEAL
2180335217100CIRCLIP
2213115027300WASHER
2313115082100SHAFT
2320516150401NEEDLE BEARING
2333115082300WASHER
2343115027400GEAR WHEEL
2350516153800NEEDLE BEARING
2370665099983SEAL
2383201195197GUIDE SLEEVE
2390663915001ORING
2503201195150ROT.CHUCK.COMPL
2523201195152ROT.CHUCK BEAR.
2540102047800PIN
2550509022200ROLLER BEARING
2560509012129ROLLER BEARING
2573115029701SHIM
2583115029702SHIM
2593115029703SHIM
2603201195144DRIVER
2613201195411ROT.CH.BUSHING
2710663212000ORING
2723201195141STUD
2733201195142STUD
3013201195109INTERMED. PART
3453115345500CONNECT. PLATE
3460211196084SCREW
3470663210062ORING
3503115298800SEAL RING
3563201195191SEAL KIT
3583201195192SEAL KIT
3603201195118DAMPING PISTON
3700686911000PROTECTION PLUG
4013201195002CYLINDER COMPL.
4023201195094CYLINDER
4153115116500STUD
4163115027600GUIDE
4203201195115SEAL HOUSE COMP
4223201195194SEAL KIT
4230663613600ORING
4253201195099PISTON GUIDE
4303201195117PISTON
4353201195004PISTON GUIDE
4403201195106SEAL HOUSE COMP
4423201195195SEAL KIT
4430663210577O-RING
4453115176500VALVE PISTON
4463115207704VALVE COVER
4473115207605VALVE COVER
4500147143803SCREW. HEX HEAD
4620663210053ORING
4700663613401ORING
4750663213301ORING
5013201195003BACK HEAD
5050147148103SCREW. HEX HEAD
FAQ
FAQ
Which rigs does the 3201195249 guide fit?
It bolts directly into Epiroc RD 22U and RD 18U surface drills. If you’re running a different model, cross‑check your parts book or send us your machine serial number — we’ll confirm compatibility.
How do I know I’m ordering the right guide?
Look for part number 3201195249 or the alternate 3201 1952 49 on your old component. Still unsure? Reach out with a photo of your rig’s feed beam and we’ll match it.
Is this a genuine Atlas Copco/Epiroc part?
Yes, it ships in OEM packaging with factory markings. Same material, heat treat, and dimensions as the guide that came on the machine.
What’s the typical lead time?
If it’s on the shelf, we ship within 1–2 business days. International courier usually adds 3–7 business days, depending on your location and selected service.
How often should this guide be replaced on an RD 22U?
Pull it for inspection at 500‑hour intervals. In abrasive overburden or hard rock you might see replacement around 1,000–1,500 hours. Swap it out before the wear grooves get deep — waiting too long beats up the feed pads and cylinder mounts.
Can I get bulk pricing or set up a dealer account?
Absolutely. We put together volume quotes and dealer programs based on your annual usage. Drop us an inquiry with your estimated quantities and we’ll work out a package.
Stock
Check Stock & Get a Quote
Tell us your rig model and quantity — we'll get back with a quote within one business hour.
