3115515200 Water pipe seat CONNECTING PLATE EPIROC 3115 5152 00 cop 1838ME/HE CONNECT

3115515200 – The ME-head water pipe seat plate for EPIROC COP drills

This is the EPIROC 3115515200 connecting plate, sometimes listed as 3115 5152 00. It bolts onto the front head of COP rock drills to anchor the water pipe seat. If you run a plain ME head (not the HD variant), this is the plate you need. It isn’t a generic copy — we supply the genuine EPIROC part.

  • EPIROC part number: 3115515200 (also stamped 3115 5152 00)
  • Fits COP 1238, 1838ME, 1838HE, 1840 with ME-type front head
  • For plain head assemblies only — does not fit HD heads (use 3115 5043 00 for HD)
  • Commonly replaced during front head rebuilds or when a water leak shows at the pipe seat
Get a Quote Back to For Epirco drifter
3115515200 Water pipe seat CONNECTING PLATE EPIROC 3115 5152 00 cop 1838ME/HE CONNECT
#277
Highlights
Key Advantages
  • Matches EPIROC ME (plain) front heads — not the HD version, so you avoid a mis-order
  • Works across several COP series: 1238, 1838ME, 1838HE, and 1840
  • Genuine EPIROC part, not aftermarket — material and fit match the factory specs
  • Direct swap for a worn or cracked plate; no drilling or re-tapping needed on the head
Use Cases
Applications
  • COP 1838ME and 1838HE drills running standard ME front head assemblies
  • COP 1238 and 1840 rock drills when a plain head is fitted
  • Underground production rigs, tunnelling jumbos, and bolters using COP ME heads
  • Workshop overhauls: front head teardown and reseal jobs
  • Replacing a leaking water pipe seat connection on-site
Specs
Technical Specifications
EPIROC part number3115515200 (also referenced as 3115 5152 00)
Part descriptionConnecting plate / Water pipe seat
Head typeME head (plain head) — NOT for HD head
Compatible modelsCOP 1238, COP 1838ME, COP 1838HE, COP 1840
HD head alternative3115 5043 00 (for HD front heads only)
MaterialHigh-strength alloy steel
ConditionNew, genuine EPIROC
Details
Detailed Description
3115515200 Water pipe seat CONNECTING PLATE EPIROC 3115 5152 00 cop 1838ME/HE CONNECT

Description:
COMPATIBLE WITH; 1238, 1838ME/HE, 1840, ETC.
Overview:
2 TYPES OF CONNECTING PLATE IS USED ON FRONT HEAD;
- FOR HD HEAD (3115 5043 00)
- FOR ME HEAD, OR OTHER WORDS PLAIN HEAD


Brand :Epiroc
Part No. :3115515200
Description :Connect. Plate
Use in :Cop 1238k , Cop 1838+ , Cop 1838he+


EPIROC - COP 1838HE+
Ref No.Part No.Description
03115160391NIPPLE SET
00686925026PLUG
00686925027PLUG
17490516217SHANK ADAPTER
17490516184SHANK ADAPTER
17490516206SHANK ADAPTER
53115223200DRILL COLLAR
53115223300DRILL COLLAR
53115223100DRILL COLLAR
103115028600DOME NUT
113115028700WASHER
203115347383HYDRAULIC MOTOR
203115347384HYDRAULIC MOTOR
203115347385HYDRAULIC MOTOR
213115027700COUPLING
220335213000CIRCLIP
243115032700GASKET
253115354800NUT
303115290080ACCUMULATOR
313115351181ACCUMULATOR
353115261592RETURN ACCUMULATOR
503115316400LABEL
513115575701LABEL
703176651200NIPPLE
713176651400NIPPLE
1003115295084FRONT HEAD COMP
1013115295000FRONT HEAD
1053115211900GUIDE
1103115212100FLUSHING HEAD
1113115238600CUP SEAL
1123115269300CUP SEAL
1203115515200CONNECT. PLATE
1240665100012CUP SEAL
1250147140103SCREW. HEX HEAD
1263315019508LOCK WASHER
1303115324500SEAL RING
1403115211780STOP RING. COMPL
1420663214501ORING
1460663210596ORING
1470663214300ORING
1513115535080COVER COMPL.
1600666719001RADIAL LIP SEAL
1610335217300CIRCLIP
1620686371606PLUG
1630661102600SEAL WASHER
1700663615100ORING
1903115534700SIDE BOLT
1910102047300PIN
2013115234080GEAR HOUSING
2120544216200GREASE NIPPLE
2140686420103PLUG
2150653903800GASKET
2170666718801RADIAL LIP SEAL
2180335216900CIRCLIP
2253115027300WASHER
2313115082100SHAFT
2320516150401NEEDLE BEARING
2333115082300WASHER
2343115027400GEAR WHEEL
2350516153800NEEDLE BEARING
2363115082400SLEEVE
2370667120600SEAL
2383115274200GUIDE SLEEVE
2390663213301ORING
2503115531380ROT.CHUCK.COMPL
2523115188100BUSHING
2550509022100ROLLER BEARING
2560509022300ROLLER BEARING
2573115029701SHIM
2583115029702SHIM
2593115029703SHIM
2603115531400DRIVER
2613115296801ROT.CH.BUSHING
2653115145700SIDE BOLT
2710663212000ORING
3013115527480INTERM. COMPL.
3023115527422INTERMEDIATE PART
3203115535802LINER
3223115328923SEAL RING
3243115328913SEAL RING
3263115536000DISK SPRING
3283115174606NOZZLE
3403115238400VALVE SEAT
3413115238300VALVE CONE
3423115329018SEAL RING
3453115345500CONNECT. PLATE
3460211196084SCREW
3470663210062ORING
3503115298800SEAL RING
3523115514601SEAL RING
3563115187900SEAL KIT
3583115188000SEAL KIT
3603115297100DAMPING PISTON
3700686911000PROTECTION PLUG
4013115194480CYLINDER
4153115116500STUD
4163115211200GUIDE
4203115527580SEAL HOUSE COMP
4223115097000SEAL KIT
4230663210576ORING
4253115167100PISTON GUIDE
4303115212600PISTON
4353115212400PISTON GUIDE
4403115276080SEAL HOUSING COMPL
4423115255400SET OF SEALS
4430663613500ORING
4453115176500VALVE PISTON
4463115207703VALVE COVER
4473115207605VALVE COVER
4500147143803SCREW. HEX HEAD
4553115329300REGULATING PIN
4563115321400NUT
4573115169700SEAL WASHER
4700663613401ORING
5013115348200BACK HEAD
5050147148103SCREW. HEX HEAD
5100663613800ORING

FAQ
FAQ
How do I know if my front head is ME or HD?
ME (plain) heads and HD heads use different connecting plates. Check your existing plate part number: if it’s 3115515200, you have an ME head. If it’s 3115 5043 00, you have an HD head. The two plates are not interchangeable.
Which COP models does 3115515200 actually fit?
It’s listed for COP 1238, 1838ME, 1838HE, and 1840, but only when the front head is the ME (plain) type. Always confirm head configuration before ordering.
What problem does replacing this plate solve?
A cracked or corroded plate often causes a water leak at the pipe seat on the front head. Swapping it out restores a tight seal and keeps flushing water where it should be — through the drill string, not down the side of the hammer.
Is this an aftermarket copy?
No. We supply the genuine EPIROC part, exactly as it comes from the OEM. Same material, same tolerances.
What’s the availability like? I need one quickly.
Stock levels move, but we usually ship within a week. If you’re down, let us check live stock and we’ll confirm a date. Express shipping can be arranged.
