3115296801 Chuck Bushing ROT CH Bushing Epiroc Bush for Drilling Rig Accessories Cop 1838hd+

3115296801 Chuck Bushing – Fits COP 1838HD+ and More, Ships Same Day

3115296801 (also 3115 2968 01) is a rotation chuck bushing for Epiroc COP series rock drills. It weighs 2 kg and sits in the rotation chuck assembly, where it takes the wear from the drill string so the chuck itself doesn't have to. If your rig is eating chuck parts or the rotation feels sloppy, this is the part that usually needs replacing first.

  • Fits COP 1238K, 1838+, 1838HD+, 1838HE+, 1838MUX, 1840+, 2238HD+
  • 2 kg. Not a lightweight copy. Machined to the original dimensions.
  • In stock now. Ships same day if ordered before 3pm.
Get a Quote Back to For Epirco drifter
3115296801 Chuck Bushing ROT CH Bushing Epiroc Bush for Drilling Rig Accessories Cop 1838hd+
#488
Highlights
Key Advantages
  • Built to original dimensions so it drops into the chuck without shimming or machining.
  • Takes the wear instead of the chuck body. Cheaper to replace than a full chuck.
  • 2 kg weight matches OEM spec. No balance issues on the rotation head.
  • Works across a wide range of COP drifters: 1238K through 2238HD+.
Use Cases
Applications
  • Epiroc COP 1238K rock drills – underground and surface
  • COP 1838+ and 1838HD+ drifters on BOOMER and similar rigs
  • COP 1838HE+ for heavy-duty face drilling
  • COP 1838MUX – fits the MUX version without modification
  • COP 1840+ and COP 2238HD+ – same bushing, same fit
Specs
Technical Specifications
BrandEpiroc
Part Number3115 2968 01 / 3115296801
DescriptionRotation Chuck Bushing
Weight2 kg
CompatibilityCOP 1238K, 1838+, 1838HD+, 1838HE+, 1838MUX, 1840+, 2238HD+
AvailabilityIn Stock
Details
Detailed Description
Brand :Epiroc
Part No. :3115 2968 01     3115296801
Description :Rot.ch.bushing
Use in :Cop 1238k , Cop 1838+ , Cop 1838hd+ , Cop 1838he+ , Cop 1838mux , Cop 1840+ , Cop 2238hd+
Weight: 2kg
In stock

3115296801 Guide Sleeve Drilling Rig Accessories Rotation Chuck Bushing Hydraulic Drifter Face Drill Rigs Spare Parts

3115296801, 3115 2968 01 Rotation Chuck, Complete Atlas Copco
Part identification

3115 2968 01 is listed as Rotation Chuck, Complete for Atlas Copco equipment. The part number is the primary ordering reference; this compatibility record does not claim genuine manufacture.

Compatibility and specifications

Exact-part catalog applications: Epiroc AB Underground drilling BOOMER S1D Published specifications: weight: 2 kg These references should be confirmed against the equipment serial number before purchase.

Brand :Epiroc
Part No. :3115600488
Description :Rot.ch.bushing
Use in :Cop 1638hd+ , Cop 1838hd+ , Cop 1838mux+ , Cop 2550+ , Cop Sc25





FAQ
FAQ
What's the difference between 3115296801 and 3115 2968 01?
Nothing. They are the same part. Epiroc uses both formats depending on the catalog year. Order either number and you get the same rotation chuck bushing.
Will this fit my COP 1838HD+?
Yes, if your rig uses the standard rotation chuck assembly. But always check your machine's serial number and parts book. There are variations in later production runs.
Is this a genuine Epiroc part?
No. This is an aftermarket replacement made to the same dimensions and material spec. It is not manufactured by Epiroc, but it fits and performs the same job.
How often should I replace the chuck bushing?
Depends on drilling conditions. In hard rock or high-rotation hours, we've seen them last 600–1000 hours. Check for play in the chuck and visible wear grooves. If the drill string wobbles, replace it.
Do you ship internationally?
Yes. We ship worldwide from stock. Delivery time depends on destination and customs, but most orders leave the warehouse within 24 hours.
Can I get a discount for multiple bushings?
Yes. Contact us with the quantity you need and we'll quote you a bulk price. We keep these in stock for regular customers.
Stock
Check Stock & Get a Quote
In stock and ready to ship. Send us your rig model and serial number to confirm fitment, or just order the part number. We'll get it out the door today.
