3115294500 Ventilator Breather rear COP 3060 Epiroc 3115 2945 00 Parts Atlas Copco drifter cop 2560

Epiroc 3115294500 Ventilator Breather – Made for COP 3060, 2560, and 2550 Series Drifters

The 3115294500 ventilator breather is a factory-spec replacement part for a range of Epiroc COP drifters. Its job is straightforward: let the gearbox breathe while stopping dust, water, and slurry from working their way inside. Threads in directly where the old breather came out—no adapters, no drilling.

This part fits the following models:

  • COP 1850 / 1850CR
  • COP 2160
  • COP 2550 / 2550+
  • COP 2560 / 2560+
  • COP 3060

If you've noticed a buildup of internal pressure or oil mist around the back head, this is often the first part worth checking.

Get a Quote Back to For Epirco drifter
3115294500 Ventilator Breather rear COP 3060 Epiroc 3115 2945 00 Parts Atlas Copco drifter cop 2560
#295
Highlights
Key Advantages
  • OEM vent breather, machined to Epiroc’s tolerances—no sealing issues from day one.
  • Threads match the back head on COP 1850 through 3060, so you can swap it in under 10 minutes.
  • Internal sintered element blocks dust and moisture in wet drilling, without choking airflow.
  • Overheating is tough on seals and O-rings; a clear breather helps pressure equalize fast during the percussion cycle.
Use Cases
Applications
  • Underground production drilling with COP 2550/2560 drifters
  • Tunnelling jumbos running COP 2160 or 3060
  • Surface bench drilling where dust and rain are a constant challenge
  • Raise boring and slot hole setups using high-output COP models
  • Rebuilds and component swaps for older Atlas Copco hydraulic drills
Specs
Technical Specifications
Part Number3115294500
BrandEpiroc
TypeVentilator breather
Compatible Drifter SeriesCOP 1850, 1850CR, 2160, 2550, 2550+, 2560, 2560+, 3060
ConditionNew, genuine OEM
Details
Detailed Description
Brand :Epiroc
Part No. :3115294500
Description :Ventilator
Use in :Cop 1850 , Cop 1850cr , Cop 2160 , Cop 2550 , Cop 2550+ , Cop 2560 , Cop 2560+ , Cop 3060

EPIROC - COP 2560
Ref No.Part No.Description
08311125601ROCK DRILL
23115345680CYLINDER COMPL.
50259031100THREAD INSERT
60259001100THREAD INSERT
70259206100THREAD INSERT
83115240100PLUG
90686644704PLUG
100661103400SEAL WASHER
113115116500STUD
123115211200GUIDE
143115297280SEAL HOUSING. COMPL
163115205300SEAL KIT
170663613600ORING
193115297300PISTON GUIDE
213115342600PISTON
243115297680SEAL HOUSE COMP
263115286900SEAL KIT
270663613500ORING
293115309400PISTON GUIDE
313115176500VALVE PISTON
323115207703VALVE COVER
333115207605VALVE COVER
340147143803SCREW. HEX HEAD
353115329300REGULATING PIN
363115321400NUT
373115169700SEAL WASHER
450663613501ORING
523115258384INTERMEDIATE PART. COMPL
533115258345INTERMEDIATE PART
550686644200PLUG
580259006800THREAD INSERT
663115347400LINER
673115374400BUSHING
680335350010LOCK RING
690663210596ORING
700663210494ORING
720196131800SET SCREW
763115238400VALVE SEAT
773115238300VALVE CONE
780663212901ORING
793115211400CONNECTION PLATE
810663210062ORING
823115298800SEAL RING
843115187900SEAL KIT
853115188000SEAL KIT
863115344100DAMPING PISTON
870686911000PROTECTION PLUG
923115348300BACK HEAD
930663613800ORING
953115294500VENTILATOR
1033115343400GEAR HOUSING
1040686420103PLUG
1050653903800GASKET
1063115343601SEAL RETAINER
1073115331300SEAL KIT
1080335217300CIRCLIP
1093115027300WASHER
1100663614400ORING
1163115343280ROTATION CHUCK COMPL
1173115343200ROTATION CHUCK
1183115343300BUSHING
1190515800015THR.NEEDLE CARR
1204090020300THR.NEEDLE CARR
1210509022200ROLLER BEARING
1220509012129ROLLER BEARING
1233115027400GEAR WHEEL
1240516150401NEEDLE BEARING
1253115082300WASHER
1260516153800NEEDLE BEARING
1273115343700BEARING SLEEVE
1280666600059RADIAL LIP SEAL
1293115343800BEARING SLEEVE
1303115343900SHAFT
1313115343100DRIVER
1323115344000ROTATION CHUCK BUSHING
1333115265200SIDE BOLT
1350663915800ORING
1360663212000ORING
1373115029701SHIM
1383115029702SHIM
1393115029703SHIM
1413115343500EXTENSION PIECE
1420686311522PLUG
1430663615100ORING
1443115331400SEAL KIT
1480570501096STRAIGHT NIPPLE
1523115345080COVER COMPL.
1533115345000COVER
1540666600060RADIAL LIP SEAL
1550335217600CIRCLIP
1570686371606PLUG
1613115287183FRONT HEAD COMPL
1623115287103FRONT HEAD
1633115296500GUIDE
1643115348400EXTRACTOR LINER
1653115347500EXTRACTOR LINER
1660335217700CIRCLIP
1673115205500SEAL KIT
1683115211600SEAL KIT
1690663614701ORING
1700663210166ORING
1813115296400EXTRACTORPISTON
1823115344800FLUSHING HEAD
1833115344900FLUSHING ADAPT.
1840661201400BACKUP RING
1853115335800CUP SEAL
1863115222100STUD
1873115265300SIDE BOLT
1880102046000PIN
1890102047600CYLINDRICAL PIN
1930663210054ORING
1970663918601ORING
1980663212601ORING
2113115290080ACCUMULATOR
2213115351181ACCUMULATOR
2313115261592RETURN ACCUMULATOR
2413115347386HYDRAULIC MOTOR
2413115347385HYDRAULIC MOTOR
2463115354800NUT
2473115032700GASKET
2483115027700COUPLING
2490335213000CIRCLIP
2513115028600DOME NUT
2523115028700WASHER
2610570500500STRAIGHT NIPPLE
2633176656800NIPPLE
2640570501049STRAIGHT NIPPLE
2913115316400LABEL
2923115345300LABEL
3007490516053SHANK ADAPTER
3007490516035SHANK ADAPTER
3007490516048SHANK ADAPTER
FAQ
FAQ
Do I need any special tools to install the 3115294500 breather?
No. It threads in by hand first, then a light snug with a wrench. Just make sure the drifter is off and the back head isn’t under pressure before you start.
How do I know if my current breather is blocked or failed?
Common signs are oil mist around the back head, a whistling noise from trapped pressure, or the drifter running hotter than usual. Unscrew it and see if the airflow is restricted.
Will this fit my older Atlas Copco COP 1838 or 1238?
It’s not listed as a direct match. We recommend cross-referencing with your serial number or checking the parts book for your specific model first.
Is there a recommended service interval for replacing breathers?
No factory-set interval, but many crews replace it when doing a seal kit change or every 2,000–3,000 rod meters if they’re in wet or gritty conditions.
What material is the breather made from?
The body is steel with a corrosion-resistant coating. The internal element is sintered bronze, designed to pass air but block fine particles.
Stock
Check Stock & Get a Quote
Check stock and request a shipping quote. We keep this breather on the shelf, and it ships same-day for orders before noon CET.
