3115247200 Atlas Copco Diaphragm 3115 2472 00 Epiroc Drill Rig cop1838 cop 1840 2238 membrane part

The diaphragm your Epiroc COP rig actually needs — straight from Atlas Copco, no surprises.

This is the Atlas Copco 3115247200 diaphragm — same as 3115 2472 00 — built for Epiroc COP 1838HD, COP 1840, and COP 2238 rock drills. It sits inside the pneumatic or hydraulic circuit handling pressure separation and control. When it gets tired, response slows down and inconsistency creeps in. Swapping in a genuine part avoids guesswork on dimensions, material behavior, and fit. No extra trimming, no second-guessing torque specs. Just pull the old one, drop this in, and get back to drilling.

Get a Quote Back to For Epirco drifter
3115247200 Atlas Copco Diaphragm 3115 2472 00 Epiroc Drill Rig cop1838 cop 1840 2238 membrane part
#255
Highlights
Key Advantages
  • Part number 3115247200 (also listed as 3115 2472 00) — matches factory drawings exactly, no adapter plates needed.
  • Handles pressure cycling in hammer and feed circuits without ballooning or cracking early, even on multi-shift sites.
  • Drop-in for COP 1838HD, COP 1840, COP 2238 — same diaphragm used across these Epiroc models simplifies your spare parts shelf.
  • Material follows Atlas Copco's compound spec, so it keeps its flexibility after months of exposure to mineral oil and temperature swings.
  • Routine replacement here keeps drill impact energy steady and reduces unplanned downtime caused by sluggish control response.
Use Cases
Applications
  • COP 1838HD — pressure regulation in percussion circuit
  • COP 1840 — membrane separation in hammer control module
  • COP 2238 — pneumatic/hydraulic interface in feed and rotation control
  • Any Epiroc surface or underground drill rig using this diaphragm reference
  • Fleet maintenance where multiple COP models share the same diaphragm stock code
  • Replacing a hardened or swollen original membrane that no longer seals properly
Specs
Technical Specifications
Part Number3115247200 / 3115 2472 00
BrandAtlas Copco (Epiroc)
TypeDiaphragm (membrane)
Compatible Drill RigsCOP 1838HD, COP 1840, COP 2238
FunctionPressure separation and control in pneumatic/hydraulic circuits
MaterialOEM-specified elastomer compound
ConditionNew, genuine Atlas Copco part
Details
Detailed Description
Atlas Copco Diaphragm 3115247200
P/N: 3115247200    3115 2472 00
CFW Original Spare Part


3115247200 is the genuine diaphragm, an essential spare part for maintaining the precise pneumatic or hydraulic control in your Atlas Copco Epiroc drill rigs. This original component ensures consistent performance, rapid response, and reliable operation by effectively managing pressure within the system.

For optimal equipment integrity and sustained high performance, insist on the genuine 3115247200 (3115 2472 00) diaphragm. This original Epiroc drill rigs part guarantees a perfect fit and exact functional specifications for your drill rig. Welcome to contact us.
